Model |
TY18218K |
||
|
Model Numbering Designation |
1, Drilling Tools 8,Mining Drills 2, Core Drills 18, Capacity (180mm) K, Kit |
||
|
Stand Height |
0.9 Meter |
||
|
Current |
Pneumatic |
||
|
Spindle |
M22*2.5 |
||
|
Rated Speed |
480 rpm |
||
|
Capacity |
Max. 180mm (7 in.) |
||
|
Drilling Depth |
Max. 1 m (3.3 ft) |
||
|
Weight |
22.0 kg |
||
|
Size |
360mm * 225mm * 370mm |
||
|
Water Pressure |
0.6 MPa(87 PSI) – 1.2 MPa(174 PSI) |
||
|
SKU |
371108 |
||
|
Working Air Pressure |
0.4 MPa(58 PSI) |
0.5 MPa(73 PSI) |
0.63 MPa(90PSI) |
|
Free Speed |
≥ 1,100 rpm |
≥ 1,250 rpm |
≥ 1,400 rpm |
|
Max. Torque |
≥ 42 Nm |
≥ 62 Nm |
≥ 76 Nm |
|
Rated Torque |
≥ 40 Nm |
≥ 50 Nm |
≥ 60 Nm |
|
Power |
≥ 1,900 W (2.5 hp) |
≥ 2,500 W (3.5 hp) |
≥ 3,000 W (4.0 hp) |
|
Air Consumption |
98 CFM |
106 CFM |
134 CFM |
|
Sound Pressure |
≤93 |
≤95 |
≤98 |
|
Sound Power |
≤ 110 dB(A) |
≤ 112 dB(A) |
≤ 115 dB(A) |
